Click-On Rotary Dimmer Module — Single-Pole

Renew a compatible rotary control with a single-pole replacement module. The rotary action combines a positive on/off click with brightness adjustment for a light controlled from one position.

Before you choose

• Single-pole configuration for one control location.
• Rotate through the click to switch on or off, then turn to adjust brightness.
• Check the original module model, mounting dimensions, load rating and supported dimming method. This is not a universal substitute for every rotary dimmer.

Dimmer Specifications

The following specifications apply to the dimmer module, with load ratings stated per dimmer.

• Dimming Type: Leading Edge (TRIAC)
• Voltage: 110–120V | 50/60Hz
• Load Ratings:
  • Dimmable LED & halogen: 3–150 W
  • Incandescent: 40–600 W
• Built-in thermal protection: automatic safety cutoff
• Temperature rating (Ta): up to 130°C (266°F)
• Mechanical life: 10,000+ dimming cycles (minimum)
• Housing: flame-retardant polycarbonate (PC)
• Fit: fits standard North American single-gang electrical wall boxes
• Certification: UL Certified (U.S. & Canada)

Single-Pole Operation

Single-Pole: Click ON/OFF while rotating the knob, then continue turning to adjust brightness. For lighting controlled from one location.

Use TRIAC-compatible dimmable lamps or drivers and follow the instructions supplied for the exact module. For multi-gang plates, the complete wall box must match the plate’s gang count; follow any required load derating when dimmers are installed together. The single-gang fit specification above refers to an individual dimmer module.

A component, not a complete fitting

This listing is for the replacement mechanism only. A decorative wall plate and complete switch assembly are not included. Match the part to your existing product rather than relying on appearance alone.

Need help identifying your part?

Contact PlatePrestige with your original order number, product link and a photo of an accessible model label. Have a qualified electrician confirm compatibility and carry out installation. Do not expose wiring to take a photograph.
