Push-On Rotary Dimmer Module — 3-Way

A replacement rotary dimmer module with a push-on/push-off action for a compatible control assembly. Turn the spindle to adjust brightness and press it to switch the light on or off.

Before you choose

• Suitable for the supported single-pole or 3-way wiring arrangement.
• A 3-way circuit provides switching from two locations; it does not automatically provide dimming from both locations.
• Confirm the module dimensions, electrical rating and lamp or driver compatibility before ordering.

Dimmer Specifications

The following specifications apply to the dimmer module, with load ratings stated per dimmer.

• Dimming Type: Leading Edge (TRIAC)
• Voltage: 110–120V | 50/60Hz
• Load Ratings:
  • Dimmable LED & halogen: 3–150 W
  • Incandescent: 40–600 W
• Built-in thermal protection: automatic safety cutoff
• Temperature rating (Ta): up to 130°C (266°F)
• Mechanical life: 10,000+ dimming cycles (minimum)
• Housing: flame-retardant polycarbonate (PC)
• Fit: fits standard North American single-gang electrical wall boxes
• Certification: UL Certified (U.S. & Canada)

Push ON/OFF Operation

3-Way: Push the knob for ON/OFF, then rotate to adjust brightness. Suitable for single-pole or 3-way wiring; in a 3-way setup, switching is available from two locations.

Use TRIAC-compatible dimmable lamps or drivers and follow the instructions supplied for the exact module. For multi-gang plates, the complete wall box must match the plate’s gang count; follow any required load derating when dimmers are installed together. The single-gang fit specification above refers to an individual dimmer module.

A component, not a complete fitting

This listing is for the replacement mechanism only. A decorative wall plate and complete switch assembly are not included. Match the part to your existing product rather than relying on appearance alone.

Need help identifying your part?

Contact PlatePrestige with your original order number, product link and a photo of an accessible model label. Have a qualified electrician confirm compatibility and carry out installation. Do not expose wiring to take a photograph.
